Cometech QC-121M2F Carton Compression tester

  • Manufacturer: Cometech
    Model: QC-121M2F
    Origin: Taiwan
    Guarantee: 12 month
  • Contact
  • Call for best price

    Hanoi: (024) 35.381.269

    Đà Nẵng: (0236) 3 74 77 11

    TP.HCM: (028) 38.119.636

  • Quality Engagement
  • Easy change and return
  • Delivery Avaliable
  • Favorable payment

Manufacturer: Cometech

Model:  QC-121M2F

Origin: Taiwan

Warranty: 12 months

Model:     QC-121M2F (A type)/ QC-121M2F (B type)/ QC-121M2F (C

 type)/ QC-121M2F (D type)

Test space:   100×100×90 cm(A type)/120×120×100 cm(B

 type)/100×100×90 cm(C type)/120×120×100 cm(D type)

Max.capacity:   2000 kg(A type)/2000 kg(B type)/5000 kg(C

 type)/5000 kg(D type)

Units exchange:   Force: gf, kgf, lbf, N, kN, ozf, tonf(SI),

 ton(long), tonf(short) Stress: Kpa, Mpa, psi, bar, mm-Aq, mm-Hg

Force resolution:   31 bits

Force precision:   1/100,000

Stroke resolution:     0.0001mm

Test speed:   Low speed mode: 0.0001 ~ 0.95mm/min

 High speed mode: 0.015 ~ 300mm/min

PC-port:   TCP/IP

Data sample rate:   1200hz(Max.)

Hardware safety protection:   upper limit, lower limit, emergency stop

Motor Type:     Servo motor

Power:   Single phase 200 ~ 240VAC・5A(A type)/Single

 phase 200 ~ 240VAC・5A(B type)/Single phase 200 ~ 240VAC・8A(type)/Single phase 200 ~ 240VAC・8A(D type)

Dimension:   159×100×170cm(A type)/179×120×176 cm(B

 type)/159×100×170 cm(C type)/179×120×176 cm(D


Weight:   approx. 800 kg(A type)/approx. 850 kg(B type)/approx. 900 kg(C type)/approx. 950 kg(D type)
