ACA: 600A /0.1A /2% ± 5 digits
ACV: 600V /0.1V /1% ± 5 digits
DCV: 600V /0.1V /1% ± 5 digits
R: 6000 Ω /0.1 Ω /1% ± 5 digits
C: 10 µF to 1000 µF /1 µF /1.9% ± 2 digits
True-RMS: yes
Continuity : yes
Hold: yes
Backlight: yes
Include: Soft carrying case,Test Leads,5xAA Alkaline batteries, User Manual
Diameter conductor: 1.3" or 34 mm max
Size: 10.905 x 3.464 x 1.629 in (277 x 88 x 4 mm)
Weight: 12 oz. (350g)
Include: Soft carrying case,Test Leads,5xAA Alkaline batteries, User Manual
Details
Features and benefits
|
- 600 A ac current measurement with fixed jaw
- 600 V ac and dc voltage measurement
- State of the art signal processing allows for use in noisy electrical environments while providing stable readings
- CAT IV 300 V, CAT III 600 V
- True-rms ac voltage and current for accurate measurements on non-linear signals
- Large, easy to read backlight display automatically sets the correct measurement range so you do not need to change the switch positions while taking a measurement
- Three-year warranty
- Soft carrying case
|
Safety conformance EN/IEC 61010-1:2001; 600V CAT III, 300V CAT IV
|
What’s the difference between the clamp meter models?
|
Fluke-365 |
Fluke-373 |
Fluke-374 |
Fluke-375 |
Fluke-376 |
Fluke-381 |
Measure ac current |
200.0 A |
600.0 A |
600.0 A |
600.0 A |
999.9 A |
999.9 A |
Measure ac current via iFlex |
|
|
2500 A |
2500 A |
2500 A |
2500 A |
Measure ac voltage |
600.0 V |
600.0 V |
600.0 V |
600.0 V |
1000.0 V |
1000.0 V |
Measure continuity |
≤ 30 Ω |
≤ 30 Ω |
≤ 30 Ω |
≤ 30 Ω |
≤ 30 Ω |
≤ 30 Ω |
Measure dc current |
200.0 |
|
600.0 |
600.0 |
999.9 |
999.9 |
Measure dc voltage |
600.0 V |
|
600.0 V |
600.0 V |
1000.0 V |
1000.0 V |
Measure resistance |
6,000 Ω |
6,000 Ω |
6,000 Ω |
60k Ω |
60k Ω |
60k Ω |
Measure frequency |
|
|
|
500 Hz |
500 Hz |
500 Hz |
Measure inrush |
|
|
100 mS |
100 mS |
100 mS |
100 mS |
Work in poorly lit areas |
Backlight |
Backlight |
Backlight |
Backlight |
Backlight |
Backlight |
Measure non-linear loads |
True-rms |
True-rms |
True-rms |
True-rms |
True-rms |
True-rms |
|
|
|
|
373 Data Sheet »
