Mecmesin TTT-300C2 Torque Tool Tester (2.5-25 N.m)

Measuring range: 2.5-25 N.m

Resolution: 0.02 N.m

Accuracy: ±0.5% of full-scale; Class 1 (DAkkS-DKD-R 3-8)

Display range: 120% of M(n)

Display type: LCD, 5-digit, 29 mm high

Interface:

• USB: USB 2.0 data communication and supply

• Hirose: Limit/overload signals, digital I/O's

Software: TTT_Certify software, Quick check or creation of calibration certificates

Supply type: Internal solar cell with storage capacitor / via USB

Temperature operation: 0-40°C

Dimension (L x W x H): 280 x 147 x 79 mm

Weight: 5 kg

Rating: IP42 (protection against falling dripping water)

Operating mode:

• Standard: Display of current value

• Peak (click + max): Peak value display (drag pointer function)

• Quick check: Five follow-up measurements with averaging

• Limit: Two separately selectable limits with upper and lower limit value
