FLIR FLIR ONE EDGE Pro 具有无线连接功能的热像仪 (400°C; 适用 IOS, Androi)

Thermal pixel size: 12 µm

Thermal resolution: 160 × 120 (19,200 pixels)

Thermal sensitivity: 70 mK

- Measurement

Object temperature range(s): -20°C to 120°C (-4°F to 248°F)

                                               0°C to 400°C (32°F to 752°F)

Operating temperature: -10°C to 50°C (14°F to 122°F), battery charging 0°C to 45°C  (32°F to 113°F)

Accuracy: ±3°C (5.4°F) or ±5%. Applicable 60 sec after start-up when the unit is within 15°C to 35°C (59°F to 95°F) and the scene is within 5°C to 120°C (41°F to 248°F)

Emissivity correction: Matte, Semi-Matte, Semi-Glossy, Glossy

Measurement correction: Emissivity; Reflected apparent temperature (22°C / 72°F)

Shutter: Automatic/Manual

- Optical data

Spectral range: 8 µm – 14 µm

Visual resolution: 640 × 480

HFOV / VFOV: 54° ±1° / 42° ±1°

Frame rate: 8.7 Hz

Focus: Fixed 30 cm – infinity

- General features

Certifications: RoHS, CE/FCC, CEC-BC, EN62133, UL1642, WEEE 2012/19/EU

Storage temperature: -40°C to 70°C (-40°F to 158°F)

Size (W×H×D): 35 mm × 37.5 mm × 149 mm (1.4 in × 1.5 in × 5.9 in)

Weight (incl. battery): 153 g (5.4 oz)

Drop tested: Drop from 2 m (6.56 ft)

- Power

Battery life: Approximately 1 h 30 min

Battery charge time: 60–90 min for fully charged. 15 min charging, from empty battery, gives 40 min operating time.

- Interfaces

Wi-Fi: 802.11 a/ac/b/g/n (2.4 and 5 GHz)

Bluetooth®: Bluetooth

Charging: Female USB-C (5V/1A)

Remote operation: Up to 30 m (100 ft) from smart device via Wi-Fi
