Bird 10-6A-MFA-10 Bi-Directional RF Attenuators (10W, 6GHz, Male/Female, SMA, 10dB)
Manufacturer: Bird Model: 10-6A-MFA-10 - Request a Quotation
- Request a Quotation
- Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Power Rating: 10 W
Connector: SMA
VSWR and Frequency Range: 1.20:1 from DC to 6 GHz
Coolant Method: Dry, Convection Cooled
Impedance: 50 Ohm
Temperature: -40 ~ 40°C (-40 ~ 104°F)
PIM: -110 dBc Min.
AC Power: None
Humidity: 95% non-condensing
Standard Attenuation Values: 10 dB
Dimensions: Dia. 2.5” x 0.9” / 64 x 23 mm
Weight: 3.5 oz./100 g
Finish: Stainless Steel
