KASAHARA H2O2-V3 Hydrogen peroxide meter (0～25mg/L)

Measurement Targets: Concentration of hydrogen peroxide in a copper-plated bath

Measuring object: low concentration

Measurement Equation: Spectrophotometry

Measurement Criteria: 0～25g/L

Presentation Resolution: 1mg/L

Repeatability: ± within 5% (FS)

Response Time: 5 seconds after power ON

Automatic power off: Hold the measured value for 5 seconds, then auto power off

Measurement time: About 1 minute each time

Self-diagnostic function: Battery voltage, poor calibration, LED degradation

Calibration: Normally only zero calibration Span calibration is performed as needed (using standard solution)

Power: AAA alkaline batteries (LR03×4) DC6V

External dimensions: 88（W）×174（D）×65（H）mm

Weight: Approx. 310g

Standard Configurations Instrument body, alkaline batteries, 4 measuring cells, measuring reagent H2O2-V2-RA 500mL, dropper (5mL), micropipette (for 0.1mL), instruction manual, warranty card, carrying case
