Mark-10 M4-20 Performance Digital Force Gauges (20 lbF / 320 ozF / 10 kgF / 10000 gF / 100 N)

Capacity & Resolution: Force gauge, 20 lbF / 320 ozF / 10 kgF / 10000 gF / 100 N

Accuracy: ±0.2% of full scale

Sampling Rate: 3.000 Hz, pulse response of 1/1.500 sec. minimum

Power:

AC adapter: 100-240VAC, 50-60 Hz, 0.3 A

Battery: Rechargeable 8.4V NiMH

Low battery indicator appears when battery level is low, and gauge powers off automatically when power reaches critical stage

Battery life: Backlight on / off: up to 7 / 24 hours of continuous use

Outputs:

USB / RS-232: Configurable up to 115.200 baud

Mitutoyo (Digimatic): Serial BCD suitable for all Mitutoyo SPC-compatible devices

Analog: ±1 VDC, ±0.2% of full scale at capacity

General purpose: Three open drain outputs, one input

Set points: Three open drain lines

Configurable settings: Digital filters, outputs, automatic shutoff, default settings, key tones, audio alarms, calibration

Safe overload: 200% of full scale (display shows “OVER” at 110% and above)

Weight: 1.0 lb [0.45 kg]

Load cell deflection: 0.010 [0.25]

Environmental requirements: 40 - 100°F, max. 96% humidity, non-condensating
