KEYSIGHT E3643A プログラマブルDC電源 (0-35V/1.4A & 0-60V/0.8A, 50W)

• Maximum power: 50 W

• Number of outputs: 1

• Output ratings (0°C to 40°C)

Range 1: 0 to 35V/1.4A

Range 2: 0 to 60V/0.8A

• Programming accuracy (@25°C±5°C):

Voltage: <0.05% + 10 mV

Current: <0.2% + 10 mA

• Ripple & noise 20 Hz to 20 MHz

Normal Mode Voltage: <5 mVpp / 0.5 mVrms

Normal Mode Current: <4 mArms

• Load and line regulation:

Voltage < 0.01% + 3 mV

Current < 0.01% + 250 μA

• Resolution:

Program < 5 mV/1 mA

Readback < 2 mV/1 mA

Meter 10 mV/1 mA

Settling time 3 < 90 ms

• Power cord: AC 100- 230 V, 47- 63 Hz

• Interface: GPIB and RS232

• Weight: 6.2 kg

• Included accessories: Power cord, output voltage wire, instruction manual
