Faith FTH100-060 大功率可编程直流电源 (60V, 167A, 10kW)

Output Voltage: 0~60V

Current: 0~167A

Power: 10kW

Dimension (mm): 482.6(W)*132.5(H)*600(L)

Weight: 25kg

AC Input: 3 Phase input, 340VAC ~ 420VAC, 47Hz ~ 63Hz

Output Voltage: 0 ~ rated voltage (Max 1500V)

Output Current: 0 ~ rated current (Max 1200A)

Output Power: 0 ~ rated power

Efficiency: 0.87(Typical)

Line Regulation: Voltage: 0.01%F.S.; Current: 0.05%F.S.

Load Regulation: Voltage: 0.02%F.S.; Current: 0.1%F.S.

Analog Programming: V/I control; Support programming voltage: DC 0 ~ 5V/DC 0 ~ 10V input

Voltage Measurement Accuracy: 0.1%+0.1%F.S.

Current Measurement Accuracy: 0.1%+0.2%F.S.

Voltage & Current Monitoring: Voltage/Current monitoring output voltage: DC 0 ~ 10V

Protection: OVP/OCP/OPP/RVP/LVP/OTP

Transient Response: Typical 1ms

Voltage Temperature Coefficient: 20ppm/°C

Current Temperature Coefficient: 40ppm/°C

Display: 4.3’’ TFT color LCD

Operation: Function key, number key, and knobs

Communication Ports: Standard RS232, LAN

Storage: 20 groups of fast recall parameters + 8 sequence files

Cooling: Air cooling

Working Temperature: 0°C ~ 40°C

Storage Temperature: -20°C ~ 70°C

Altitude: <2000m
