MICROTEST 6365A LCR 测试仪 (0.1Hz- 200kHz)

Specifications

Frequency: 0.1Hz-  200kHz

Frequency Setting: Continuity

Frequency Resolution: 5 Digits

Frequency Output Accuracy: ±0.01%

Basic Accuracy: ±0.05%

AC Drive Level:

+ Test Signal Voltage Level: 10mV - 2Vrms

+ Voltage Minimum Resolution: 1mV

DC Drive Level:

+ Test Signal Voltage Level: 10mV - 2Vrms

+ Voltage Minimum Resolution: 1mV

Output Impedance: 100Ω

Measurement Mode: Meter mode, list mode

Measurement Parameters: |Z|、|Y|、θ、X、R、G、B、L、D、Q、DCR、C

Test Time (Fastest): AC / DC test speed Max. 8mS

Measurement Parameters:

|Z| 0.001mΩ - 99.999MΩ

R, X 0.001mΩ - 99.999MΩ

|Y| 0.1nS - 99.999S

G, B 0.1nS - 99.999S

θ ±0.001 ~ ±180.000deg

Cs, Cp 0.01pF - 9.9999F

Ls, Lp 0.1nH - 99.999KH

D 0.00001 - 9.9999

Q 0.1 - 9999.9

Δ -9999% - 9999%

Rdc 0.001mΩ - 99.999MΩ

System:

Measurement Circuit: Series/Parallel

Correction: Open Circuit/Short Circuit

Indicator: PASS/FAIL

Test Range: Automatic/Lock

BIN: Yes

List Mode: 8 sets

Bulit-in Storge: 128 sets

USB Host Storge: LCR setting documents, list mode setting document

 Trigger Test: Auto, manual, RS-232, GPIB, Handler

Power Supply: Voltage：98-132Vac or 195-264Vac  (Switchable); Frequency：47-63Hz

Power consumption: 30VA

Environment: Temperature：10℃-40℃; Humidity：20-90%RH

Dimension: 358x148x343 mm (W*H*D)

Weight: 3 Kg

Interface: RS-232、Handler、LAN、USB Host

Display: Color Screen, 7" TFT (800*480)
