Weight: Approximately 48 lb. (21.9 kg)
Dimensions: 18" W x 20" D x 2.7" H (457mm W x 508mm D x 68.6mm H)
Payload Range: 205 - 252 lb(93 - 114.3 kg)
- Horizontal frequencies are weight dependent.
- Horizontal frequency of ~1.5 Hz is achieved at or near the upper limits of the payload range.
- At the lower payload weights the horizontal frequency will increase.
- Vertical frequency is tunable to 0.5 Hz throughout the payload range.
