Weight: Approximately 80 lb (36 kg)
Dimensions: 16.8" W x 16.8" D x 8.5" H(427mm W x 427mm D x 216mm H)
Payload Range: 20-55 lb(9-25 kg
- Vertical natural frequency of 1/2 Hz or less can be achieved over the entire load range.
- Horizontal natural frequency is load dependent. 1/2 Hz or less can be achieved at or near the nominal load.
- See Performance for a typical transmissibility curve with 1/2 Hz natural frequency.
