Range: 1.0" / 25.4 mm
Resolution: 0.00005" / 0.001 mm
Response Speed: 20 in / s
Measuring Force: 150 gf / 5.3 ozf (adjustable force, min. 25g)
Output: Serial BCD, Optional RS-232C, USB, MTI and Analog outputs
Stem Diameter: 3/8" (.375")
Contact Point Thread Size: AGD 4 / 48
Operating temperature: 41° to 104° F / 5° to 40° C
Power Supply: AC Adapter (120V) Built-in 8-hour rechargeable battery
Dimension: L-4.4" W-2.0" TH-1.5"
Weight: 6.3 oz / 180 g
Standard accessories: Finger lifter, AC adapter, lug back and contact point. Optional Outputs: RS-232C, USB (plug & play) MTI, Analog, Upper & Lower relays. Now Available: Wireless Data transfer interface, please ask for quote. note: EG-225 is not compliant with RoHS10 and non CE compliance
(Only 120V AC Adapter available), Prices are subject to change at any time.
